Product code: polyfilm – BPP

Compounds: Bitumen standard base +NB +A.P.P/EMPDM +Talk Powder +P.P + P.E
Booster layers: Fiberglass tissue + polyester nonwoven 100 gr
Inner surface: polyethylene film
Outer surface: polyethylene film



Title properties

 No. of test standard Unit The accepted standard

The results of

Bam Gum Ayegh

Length - Width - Weight - Thickness

 ISIRI 3878 mm,Kg,m,m 10,1,41,4 10,1,41,4
Tensile  strength MD ISIRI 3882 Kgf/5cm 40 50
CD ISIRI 3882 Kgf/5cm 30 35

Resistance to tearing

 MD ISIRI 3863 Kgf 12 20
CD ISIRI 3863 Kgf 12 18
Flexibility  at low temperature ISIRI 3881 C 0 0
High heat resistance

ISIRI 3862

 C 120 120
Water absorption

ISIRI 3879

 % -1% -1%
Water impermeability

ISIRI 3861

 Kpa 60 60



Product code: Aluminium – BPP

Compounds: Bitumen standard base +NB +A.P.P/EMPDM +Talk Powder +P.P + P.E
Booster layers: Fiberglass tissue + polyester nonwoven 100 gr
Inner surface: polyethylene film
Outer surface: Aluminum Foil



Title properties

 No. of test standard Unit The accepted standard

The results of

Bam Gum Ayegh

Length - Width - Weight - Thickness

 ISIRI 3878 mm,Kg,m,m 10,1,41,4 10,1,41,4
Tensile  strength MD ISIRI 3882 Kgf/5cm 40 50
CD ISIRI 3882 Kgf/5cm 30 35

Resistance to tearing

 MD ISIRI 3863 Kgf 12 20
CD ISIRI 3863 Kgf 12 18
Flexibility  at low temperature ISIRI 3881 C 0 0
High heat resistance

ISIRI 3862

 C 120 120
Water absorption

ISIRI 3879

 % -1% -1%
Water impermeability

ISIRI 3861

 Kpa 60 60





Product code: Polyfilm & Aluminium surface – BPP

Waterproofing membrane with high quality A.P.P modified and reinforced with SPUNBOND polyester fabric.



Compounds: Bitumen standard base +A.P.P/EMPDM +Talk Powder+P.P + P.E
Reinforcement core : spunbond polyester 160 gr
Inner surface : polyethylene film
Outer surface : polyethylene film and aluminum foil



Title properties

 No. of test standard Unit The accepted standard

The results of

Bam Gum Ayegh

Length - Width - Weight - Thickness

 ISIRI 3878 mm,Kg,m,m 10,1,41,4 10,1,41,4
Tensile  strength MD ISIRI 3882 Kgf/5cm 50 65
CD ISIRI 3882 Kgf/5cm 40 45

Resistance to tearing

 MD ISIRI 3863 Kgf 10 14
CD ISIRI 3863 Kgf 10 15
Flexibility  at low temperature ISIRI 3881 C -5 -5
High heat resistance

ISIRI 3862

 C 120 120
Water absorption

ISIRI 3879

 % -1% -1%
Water impermeability

ISIRI 3861

 Kpa 60 60
